KC 1
Country:  Europe      Brand:  Common tube type Europe
  Developer:  Telefunken Deutschland (TFK)
  Tube type:  Triode, vacuum   Universal
Identical to KC1 = KL70419 = R1862 = B21_Mazda = LV3_Triotron = LV205 = R215 = 266
Similar Tubes B240S (other base)   R208 (other base)   RC210 (can normally be replaced - small diff'ce)   ResistoR2 (can normally be replaced - small diff'ce)   ResistoR4 (can normally be replaced - small diff'ce)   T204_4pin (can normally be replaced - small diff'ce)   A225_4pin (can normally be replaced - small diff'ce)   KL70419_p8 (other base)   1-2 (can normally be replaced - small diff'ce)   KC1_Topf (other base)
First Series   1934 Tube leaflet collection E.Erb Analysis by original leaflets
First Source (s) Apr.1934 : Funk, Die Zeitschrift des Funkwesens # 14
Successor Tubes KC4
Base Europe 4-Pin (A, 4A, B4, since 1914)
Was used by Radio/TV-reception etc.
Filament -: Direct / -: Battery = /
Description Die ursprüngliche KC1 ist eine Röhre mit Stiftsockel. Es gibt auch eine Topfsockelröhre mit elektrisch gleichen Werten und gleich bezeichnet!
Text in other languages (may differ)
Tube prices 3 Tube prices (visible for members only)

Usage in Models   4= 1934  1= 1935??  12= 1935  2= 1936??  3= 1936?  24= 1936  20= 1937  8= 1938  1= 1939?  18= 1939  4= 1940  2= 1941  1= 1942  1= 1943  1= 1944  1= 1947?  1= 1948
Number of Models with this tube   104
